第一步工艺性能参数：Main Technical Parameters

机型 Model	CLFQ-B1100	CLFQ-B1300	CLFQ-B1600
质料宽度 MAX.Width of raw material	1100mm	1300mm	1600mm
放卷直径 Max.parent Web Diameter	Φ800mm	Φ800mm	Φ800mm
收卷直径 Max.Rewinding Diameter	Φ600mm	Φ600mm	Φ600mm
机器速率 Max.Machine Speed	10-350m/min	10-350m/min	10-350m/min
资料厚度 Thickness of raw material	0.008-0.2mm	0.008-0.2mm	0.008-0.2mm
总功率 Total Power	14KW	16KW	19KW
分量 Machine Weight	3800kg	4300kg	4800kg
形状尺寸 Overall Dimensions	2650×2500×1350mm	2650×2750×1350mm	2650×3050×1350mm
分切宽度 Min.Slitting Width	圆刀Round Blade :30mm	直刀Razor Blade :30mm

可遵照生成物表单提交 个人定制武器。

C💎an be made according to the product requires special equipment.

声明函及杭州特色:

1、该型分切机合适于分切PE、PP、PET,PVC等塑料薄膜，复合膜，

膜，印刷膜、圈筒纸等。是贴膜、薄片二级制造和印刷包装袋中小型企业的豪情壮志苹果机型。2、零部件加工由PLC集齐放肆（三失量机电专业）并采纳摸屏组排游戏界面对零部件加工消停集齐控制。3、放卷使用自动行车盘式制动器行车盘式制动器器，由PLC分手后权较劲卷径成功完成分手后权张度放肆。4、制动有有节制由一部失量直流变频机械驱动器，完毕恒线效率有有节制，并穿透范围收放卷弹力期间的互相影响力。5、收秘药容纳气涨轴收卷由二台矢量图定频电气自动化自力驱动程序，收卷涨力控制，根据收卷内直径，模切钢板厚度，调整涨力等参数值，由PLC运算进行积极涨力增长。（必选滑差气涨轴轴）6、收秘药辊轴聚散进行气动系统配置，工作压力非己沿途的过程 调压阀控制。7、放卷装运垃圾料敞开心扉气涨轴装运垃圾料，汽动伸缩，料卷汽动起伏，装运垃圾料便捷性、法律效力高。8、放卷EPC纠编转配可精确度吃妻上瘾端口gps精度。9、模切机进行圆刀直刀模切机自动装配，激光切割端面洁净，有边垃圾风送。10、所需要的零部件由微信同部带、微信同部轮为传输体例，明确与拉紧认识自己气动弹簧体例11、牵引带导辊：静多样化铝不锈钢导辊，外貌软化妥善处理 12、管理体系提供进行响应、停车防松、计米定长，定速、卷径运算评分切功效与作用。13、风险管理体系兼具很好的的机、电、气成集成化构想，并容纳齐全的隔离技巧。

Description and characteristics:

1. This type of slitting machine is suitable for slitting PE, PP, PET, PVC and other plastic films, composite films,

Film, color film. It is the ideal model for film and sheet secondary processing and color printing p⛄ackaging enterprises.

2. The whole machi꧒ne is controlled by PLC (three vector motor) and uses the touch screen man-machine interface to carr♚y out centralized operation of the whole machine.

3. The unwinding adopts 🐻the start brake brake, and the automatic calculation of the coil diameter is realized by the PLC.

4. The traction control is driven by a vector variable frequency motor to achieve constant line speed control and effectively interrupt ✱the interaction between the tension of the rewinding and unwinding.

5. The reel is wound by the air-up shaft and driven by two vector inverter motors. The winding tension control is based on the winding diameter, the thickness of the slit, the tension and othﷺer parameters. The automatic tension is incremented by the PLC operation.（Optional Differentiaဣl Air Shaftrs）

6.🌳 The take-up reel is clutched with a pneumatic device, and the pressure is controlled by a pressure regulating valve.

7. The unwinding loading and unloading material adopts the gas-up shaft loading and unloading 🦂material, pneumatic locking, pneumatic lifting of the material roll, con🎐venient loading and unloading, and high efficiency.

8. The unwinding EPC correction device can accuratel𝕴y control the end face precision.

9. The cutting machine adopts a round knife straight knife slitt💧ing device, the en❀d surface is neat, and there is a side scrap air supply.

10. The whole machine is driven by synchronous belt and synchron♛ous wheel, and pneumatically operated by locking and locking.

🧜11. Traction guide rolle💞r: static balance aluminum alloy guide roller, surface hardening treatment

12. The system has the functions of starting buffering, parking anti-loose, metering le﷽ngth, constant speed, and coil diameter c𒈔alculation.

13. The system has a complete integrated design of machine, electricit𒈔y and gas, and adopts complete safety protection measures.
